ARC ELECTRUS Series

ARCTOS proudly presents the ELECTRUS Series. Sporting an innovative CNC housing, the crisp beam quality and bright colours will electrify your mind. With a compact, lightweight form, it's easy to handle and transport.

ARC ELECTRUS 6W

Datasheet ELECTRUS 6W

MAXIMUM OUTPUT	8.7W
637nm ARC RED	3.1W 1.2mrad
520nm ARC GREEN	1.8W 0.3/0.8mrad
445nm ARC BLUE	3.8W 0.3/0.8mrad

Beam Size Analog Modulation Operational Voltage	5.5mm 0-5V up to 50kHz 110-240 VAC @ max. 850W

ARC ELECTRUS 16W

Datasheet ELECTRUS 16W

MAXIMUM OUTPUT	17.4W
637nm ARC RED	6.2W 1.2mrad
520nm ARC GREEN	3.6W 0.3/0.8mrad
450nm ARC BLUE	7.6W 0.3/0.8mrad

Beam Size Analog Modulation Operational Voltage	6mm 0-5V up to 50kHz 110-240 VAC @ max. 850W

ARC ELECTRUS 24W

Datasheet ELECTRUS 24W

MAXIMUM OUTPUT	28.2W
637nm ARC RED	8.2W 1.2mrad
520nm ARC GREEN	8.5W 0.5/0.9mrad
450nm ARC BLUE	11.5W 0.5/0.9mrad

Beam Size Analog Modulation Operational Voltage	6mm 0-5V up to 60kHz 110-245 VAC @ max. 995W

ARC ELECTRUS 36W

Datasheet ELECTRUS 36W

MAXIMUM OUTPUT	41.9W
638nm ARC RED	6.2W 1.2mrad
658nm ARC RED	7.2W 1.2mrad
520nm ARC GREEN	10.5W 0.5/0.8mrad
445nm ARC BLUE	18.0W 0.5/0.8mrad

Beam Size Analog Modulation Operational Voltage	8mm 0-5V up to 50kHz 110-240 VAC @ max. 1.2kW

ARC ELECTRUS 66W RGBY

Datasheet ELECTRUS 66W RGBY

MAXIMUM OUTPUT	81.1W
638nm ARC RED	11.0W 1.2mrad
658nm ARC RED	12.8W 1.2mrad
520nm ARC GREEN	22.0W 0.5/0.8mrad
445nm ARC BLUE	30.0W 0.5/0.8mrad
577nm COHERENT OPSL	6.0W 0.3mrad

Beam Size Analog Modulation Operational Voltage	10mm 0-5V up to 50kHz 110-240 VAC @ max. 1 kW
