Our exceptional ARC OPSL series projectors feature high end Arctos DLP40-T drivers, coupled with 100% Coherent Genesis Taipan OPS Lasers, for laser show professionals demanding premium performance of their investment over an extended lifetime.
_
 |  |  |
MAXIMUM OUTPUT | 17.0W |
639nm RED | > 5.0W (Coherent OPSL) |
532nm GREEN | > 5.0W (Coherent OPSL) |
577nm YELLOW | > 5.0W (Coherent OPSL) |
460nm BLUE | > 2.0W (Coherent OPSL) |
Beam Data Standard Operational Voltage | Beam Size: < 2,5mm Divergence: < 1,0mrad |
_
MAXIMUM OUTPUT | 20.0W |
639nm RED | > 5.0W (Coherent OPSL) |
532nm GREEN | > 8.0W (Coherent OPSL) |
577nm YELLOW | > 5.0W (Coherent OPSL) |
460nm BLUE | > 2.0W (Coherent OPSL) |
Beam Data Standard Operational Voltage | Beam Size: < 2,5mm Divergence: < 1,0mrad |
_
MAXIMUM OUTPUT | 25.0W |
639nm RED | > 5.0W (Coherent OPSL) |
532nm GREEN | > 10.0W (Coherent OPSL) |
577nm YELLOW | > 6.0W (Coherent OPSL) |
460nm BLUE | > 4.0W (Coherent OPSL) |
Beam Data Standard Operational Voltage | Beam Size: < 2,5mm Divergence: < 1,0mrad |
Dimensions | 303mm(H) x 503mm(W) x 348mm(L) |
ILDA Standard D-Sub 25p | In-/ and output |
| | |  |
 |  |  |  |
 |  |  |  |
CERTIFIED ARCTOS OPSL DRIVER | DLP 40-T |
The ARC OPSL SERIES is provided with a processor controlled internal thermoelectric cooling of heat-generating components and exceptional internal heat dissipation. | |
Operational Temperature | 8°C up to 30°C [optimal operation temperature: 25°C] |
Scanning System Standard | CT 6800 / 35 kpps@8° with 1M0 |
+ Compact solid housing made by ARCTOS
+ Integrated scanner plug`n play concept
+ Best stability and lifetime
+ Designed for laserprofessionals!
+ Dynamic Zone Safety
+ Energy Saving
+ Super Silent
+ ESD Protected Stabilized Switching Power Supplies
+ Microprocessor controlled
+ ARC-Modular construction
+ YOKE designed against shear forces
+ DMX Ready
+ Ethernet Ready
CNC-milled black anodized aluminium
Mechanical levitated design
Automatic cooling/heating for optimal laser parameters
Dust proof optical compartment
Maintenance free and long lifetime
Ultra rugged, compact and reliable housing design
+ The new electric mainboard manufactured by ARCTOS allows many system features |
ARC-Remote control unit incl. CDRH-standard & time delay max.cable length 60m
Interlock AMP safety-standard for illuminated "Emergency"
Integrated Pangolin Flashback
RGB potentiometers
Gratings (holographic mirrors)
Customized Climate box for outdoor installations
Customized Flightcases Made by Amptown
|
|
