Single color Laserprojectors from 1W up to >20W output power. Obtaining rich and vibrant laser colors for your next lightshow with Coherent's Genesis Taipan laser family combined with strong ARCTOS® technology. We offer the complete Coherent-OEM module laser spectrum of Genesis Taipan Series, custom-designed for laser professionals.
100% Coherent© Taipan© OPSL Technology incl. ARCTOS© original Driver Series DLP
OPSL Red 639nm | 1.0W |
| |
OPSL Red 639nm | 1.5W |
| |
OPSL Red 639nm | 2.0W |
| |
OPSL Red 639nm | 2.5W |
| |
OPSL Red 639nm | 5.0W | | |
OPSL Red 639nm | 10.0W | ||
Analog Modulation | 0-5V up to 50kHz | ||
Dimensions | 185mm(H) x 320mm(W) x 370mm(L) |
Scanning System Standard | CT 6800 with 1M0 incl. scan fail safety |
+ Compact solid housing made by ARCTOS
+ Integrated scanner plug`n play concept
+ Best stability and lifetime
+ Designed for laserprofessionals!
High-speed Scanners CT6800 and CT6215 controlled by Servoamp 1M0 guarantee
an excellent projection quality at speeds up to 60.000 pps. at 7 °projection
angle accordingly to ILDA standard.
Easy control and compatibility to other Lasersystems: the user is able to
assign at the backside of the system the Invert function of X and Y scanner
as well as the modulation parameters for blanking or for the corresponding
color channel.
Excellent beam parameters from up to 0.4 mrad and analog modulation >50 kHz
guarantee pin sharp graphic projections with clean fading also for long
projection distances.
Integrated visual status display of all system parameters and DMX-address
setting tool for an internal output card (optionally available).
CERTIFIED ARCTOS OPSL DRIVER | DLP 40-T |
CNC-milled black anodized aluminium
Mechanical levitated design
Automatic cooling/heating for optimal laser parameters
Dust proof optical compartment
Maintenance free and long lifetime
Ultra rugged, compact and reliable housing design
ARC-Remote control unit incl. CDRH-standard & time delay max.cable length 60m
Interlock AMP safety-standard for illuminated "Emergency"
Integrated Pangolin Flashback
RGB potentiometers
Gratings (holographic mirrors)
Customized Climate box for outdoor installations
Customized Flightcases Made by Amptown
|
|
